Super X-Strut Heavy-Duty Vehicle Stabilization Strut

Heavy-Duty Vehicle Stabilization & Lifting Strut

Our heavy-duty vehicle stabilization struts have rated lifting loads up to 6,000 lbs. and span lengths from 51.5" to 100".

Super X-Strut® Our Stongest Heavy-Duty Lifting Strut

Heavy-Duty Vehicle Stabilization and Lifting Strut

Super X-Strut® Our Stongest Heavy-Duty Lifting Strut

The Super X-Strut® is our premium stabilization and lifting strut. and is capable of stabilizing and lifting large vehicles as well as structural collapse and mine rescue. The Super X-Strut® is milled from solid aluminum and features threaded collars instead of our standard pins, making it our strongest and fastest-deploying strut. These struts are available in two sizes to accommodate a variety of situations. Ask about solid inner tubing for even more stabilization power.

  • Downloads

  • Technical Data Sheet (309KB)

  • Quick Reference Guide (13MB)

  • Product Catalog (8MB)

  • Specifications

Column WLL
19,300 lbs.
19,300 lbs.
Lifting WLL
6,000 lbs.
6,000 lbs.
Extended Height
68.5"
68.5"
Collapsed Height
51.5"
51.5"
Weight
36 lbs*
36 lbs*
Column WLL
19,300 lbs.
19,300 lbs.
Lifting WLL
6,000 lbs.
6,000 lbs.
Extended Height
100"
100"
Collapsed Height
67.5"
67.5"
Weight
46 lbs*
46 lbs*

(2:1 safety factor on Struts & Accessories)

Strut weight includes Hollow Inner Tubing, Swivel CRG Head Fitting, Extrication Base Plate, and all hardware. One Ratchet Strap with Wire Hooks is included with each strut. Add-On Jack weight: 25 lbs. WLL tested with hollow inner tubing and extrication end fittings at 6' extension. (Call about solid inner tubing) See Technical Data Sheet for full specs.

Questions? Give us a call 1-800-466-9626

Benefits of a Res-Q-Jack® brand Super X-Strut® Heavy-Duty Lifting Strut
Super X-Strut® Our Stongest Heavy-Duty Lifting Strut

1. Swivel CRG End Fitting

The Super X-Strut® comes standard with our Swivel CRG head fitting which gives you a variety of purchase point options and rotates 360° to easily find any purchase point.

2. Quick-Release End Fittings

Change end fittings in an instant with the pull of a single retaining pin.  Because Super X-Strut® is compatible with other manufactures end fittings, you can swap out with neighboring departments during mutual aid response.

3. Pin-Free Operation

The Super X-Strut® threaded tube design eliminates the need for pins, making set-up faster than ever.  The threaded tube allows for infinitesimal height adjustment when stabilizing or lifting and lowering loads.

4. Aluminum Construction

The Super X-Strut® is milled from solid 6061-T6 aluminum for superior strength when shoring, stabilizing and lifting, without adding weight.

5. X-Strut® Lifting Power

The Super X-Strut® transforms from a shoring strut to a lifting strut in seconds with our removable mechanical Add-On Jack, giving you 6,000 lbs. of lifting capacity with 12 inches of travel.

Need to lift more than a foot?  Just remove the pin-free Add-On Jack and reset for 12 more inches of lift.

6. Available Air Fitting

Ask about having the Super X-Strut® milled with our air fitting for use with pneumatic systems.

7. Base-Mounted D-Rings

Pivoting rings built into the base plate allow for fast attachment of straps, hooks and chains, or double as a picket receiver when anchoring is needed.
